Distance Measurement: The device realizes distance measurement function after marking the top and bottom of target, and input the target height. Hot Spot Mark: The device detects and marks the hot spot of highest temperature. Mode Switch: Device supports pallet switch and distance measurement. Storage: Built-in memory module supports video recording/snapshot capturing. Digital Zoom: Device supports 1×, 2×, 4×, and 8× digital zoom. Wi-Fi Hotspot: Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

Interface USB Type-C Pixel Interval 12 μm Multi Language menu Yes Drop Test Height 1.5 m (4.9 feet) Digital Magnification 2.5x - 20x Detector type Vanadium Oxide Uncooled Focal Plane Arrays Response Waveband 8μm to 14μm FFC (Flat Field Correction) Auto, Manual, External Correction Highest Temperature Spot Tracking Yes Standby Mode Yes Refresh rate 50 Hz Aperture F1.0 Resolution 384×288 Detection Range (6' object) 1180m/yd NETD Less than 35 mk (@25°C), F#=1.0 Lens (focal length) 25 mm Power 5 VDC/2 A, 1.5 W Field of view (H × X) 10.5° × 7.9° (H × V) Digital zoom 2×, 4×, 8× Monitor 1280×960, 0.4 inch, LCOS Imaging palettes Black Hot, White Hot, Red Hot, Fusion Storage Built-in memory module (8 GB) Record Video On-board video recording Capture Snapshot Yes Battery Type Built-in rechargeable Lithium battery Wi-Fi Yes CVBS Output Yes (via USB) Battery Operating Time -20°C to 55°C (-4°F to 131°F) Battery Capacity Display Yes Weight 300 g (0.69 lb) Working Temperature/ Humidity -20°C to 55°C (-4°F to 131°F) Overall Dimensions 171 × 61 × 57 mm (6.73 × 2.4 × 2.2 in) Protection Level IP67 Magnification 2.5x
