Distance Measurement: The device realizes distance measurement function after marking the top and bottom of target, and input the target height. Hot Spot Mark: The device detects and marks the hot spot of highest temperature. Mode Switch: Device supports pallet switch and distance measurement. Storage: Built-in memory module supports video recording/snapshot capturing. Digital Zoom: Device supports 1×, 2×, 4×, and 8× digital zoom. Wi-Fi Hotspot: Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

Palettes Black Hot, White Hot, Red Hot, Fusion Working Temperature -20°C to 55°C (-4°F to 131°F) Interface USB Type-C Pixel Interval 12 μm Multi Language menu Yes Drop Test Height 1.5 m (4.9 feet) Digital Magnification 1.5x - 12x Detector type Vanadium Oxide Uncooled Focal Plane Arrays Response Waveband 8μm to 14μm FFC (Flat Field Correction) Auto, Manual, External Correction Highest Temperature Spot Tracking Yes Standby Mode Yes Refresh rate Sensor 25 Hz / OLED 50 Hz Aperture F1.0 Resolution 256×192 Detection Range (6' object) 710m/yd NETD Less than 35 mk (@25°C), F#=1.0 Lens (focal length) 15 mm Power 5 VDC/2 A, 1.5 W Field of view (H × X) 11.69° × 8.78° (H × V) Digital zoom 1×, 2×, 4×, 8× Monitor 720×540, 0.2 inch, LCOS Storage Built-in memory module (8 GB) Record Video On-board video recording Capture Snapshot Yes Battery Type Built-in rechargeable Lithium battery Wi-Fi Yes CVBS Output Yes (via USB) Battery Operating Time Up to 8 hours continuous running (with Wi-Fi hotspot function off) Battery Capacity Display Yes Weight 280 g (0.62 lb) Overall Dimensions 158 × 61 × 57 mm (6.23 × 2.4 × 2.2 in) Protection Level IP67 Magnification 1.5x
